Crown GS-30 Gas Tilting Skillet with 30 Gallon Capacity

The Crown GS-30 gas tilting skillet features a stainless steel cover with spring assist hinges, a full-width handle, a no-drip condensate guide, and a vent port with a swing cover. The pan has a sloped front and a front-hinged for easy tilting pour control, complete with a removable pour strainer and etched gallon markings. The pan is formed from 10 gauge type 304 stainless steel with a #4 finished exterior and polished interior with coved corners for ease of cleaning. The cooking surface is made of 3/4" triple-ply construction with a 3/8" think aluminum core ensuring even heat distribution over the entire cooking surface. Its pan is heated with stainless steel atmospheric burners with intermittent pilot ignition

The pan is mounted on a heavy-duty welded frame with stainless steel exterior supported by an all-welded 1-5/8" stainless steel pipe frame with adjustable bullet feet and rear legs fitted with flange adjustable feet for securing to the floor. The unit has a permanently lubricated, self-contained gear box tilt mechanism to allow the pan to tilt forward for the complete emptying of contents. The controls enclosure is designed to meet NEMA-2 and provides a degree of protection against dripping and light-splashing water. The unit also includes a solid-state thermostat with an OFF position and a range of 100-450°F. A thermostat indicator light, an ignition indicator light, a pan tilt switch that shuts burners off if tilted more than 5°, and a high-temperature cut-off set at 500°F.

Features and Benefits:

• 304 Stainless Steel Liner
• Manual tilt
• Pour strainer
• 4" vent port
• Etched gallon markings
• Flanged feet
• Electronic ignition

Specifications

• Model: GS-30
• Capacity: 30 Gallons
• Dimensions: 72.38"H x 36"W x 46.75"D
• Shipping Weight: 550 lbs
• BTU per Hour: 100,000
• kW per Hour: 29.3
• Electrical: 120V/60/1PH
