Crown DCX-2-24 Direct Steam Floor Model Convection Steamer

The Crown DCX-2-24 Direct Steam Convection-Type Floor Model Steamer features a direct non-toxic steam, incoming at a minimum of 15 psi (103 kPa) with a flow of 80 lbs (36 kg) per hour, alongside a pressure reducing valve that provides a manifold pressure of 7 psi (49 kPa) per hour. A cold-water supply at 25-50 psi (170-345 kPa) is required to control the drain temperature. This design allows for a reliable and efficient product.

Features and Benefits:

• A control housing constructed of stainless steel with a full access removable side panel.
• A steamer constructed of satin finish stainless steel, type 304 with a cooking chamber of one piece all welded 316 stainless steel.
• Timing for each cooking compartment that is independently controlled by a “60” minute timer, a green ready pilot light and a red cook pilot light.
• The steamer features removable stainless steel pan supports and a stainless steel drip trough connected to drain in order to collect condensate when door is opened.
• Doors feature a removable inner liner of stainless steel with full perimeter gasket seal, an outer liner of one-piece all welded stainless steel and a positive lock and seal mechanism.

Specifications:

• Pan Capacity: (6) 12’’ x 20’’ x 1’’
• Voltage: 120v/60/1-ph, 4.0 amps
• Dimensions 55.5(h) x 24(w) x 33(d)
• Weight: 450 lbs
• Stainless Steel Type: 304 construction, 316 interior
• Warranty: 1-year standard
